Square Excellent Thermal Ccm Mould Tube 8mm Copper Tube 135 X 135mm

Product Categories
Henan Genghong Industrial Co., Ltd.
Contact Now

Square Excellent Thermal Ccm Mould Tube 8mm Copper Tube 135 X 135mm

  • 1
  • 2

Model Number : 135-135mm

Certification : IOS

Place of Origin : Luoyang,China

MOQ : 2 Pieces

Price : Negitionable

Payment Terms : L/C, D/A, T/T, D/P

Supply Ability : 30000 Piece/Pieces per Year

Delivery Time : 15-30work days

Packaging Details : Wooden Case or customized

Name : COPPER MOLD TUBE

Material : CuAg/CuCrZr

specification : 135X135mm

Yield per piece : ≥ 6000 Ton per casting tube

Cu(Min) : 99%

Application : Continuous Casting Machine

Ultimate Strength (≥ MPa) : 405

Wall Thickness : 8mm ordrawing custom

Contact Now

Square 135x135mm Excellent thermal conductivity Continuous Casting Mould Tube con cast Machine

product introduction

Copper tube is one of the core equipments of ccm continuous billet caster. It makes high temperature liquid steel solidify and crystallize rapidly to form steel castings. After electromagnetic induction stirring, the liquid steel in the copper mould is cooled and shaped, and then the casting is pulled out, and then the slab is divided into predetermined length by flame cutting machine .

Product features

1, Our company can design the best internal geometry for customers according to the actual situation of steel making, and ensure better use effect and competitive cost performance.

2, Our company electroplating using the most advanced technology in Europe, can ensure that the plating solution is uniformly attached to the inner surface of the copper tube

Parameters

Copper Mould Tube Size (mm) Thickness (mm) Length (mm) Radius (mm) Design or Taylor-Made
ODM & OEM
Billet Square 50x50 - 680x680 6 - 80 600 - 1250 3000 - 17500 Exactly follow your drawing and requirement
Copper Mold Tubes or straight
Bloom Rectangle 50x50 - 680x680 10 - 80 600 - 1250 3000 - 17500 Exactly follow your drawing and requirement
Copper Mould Tubes or straight
Slab Copper Mold Tube 50x50 - 680x680 6 - 80 600 - 1250 3000 - 17500 Exactly follow your drawing and requirement
or straight
Beam Blank Mould Tube 550-150 x 120-70 12 - 80 600 - 1250 3000 - 17500 Exactly follow your drawing and requirement
or straight

Application

The copper mould tube is widely used in steel continuous casting machines. The main function of copper mould tube is to solidify the molten steel to the required size and shape.

Square Excellent Thermal Ccm Mould Tube 8mm Copper Tube 135 X 135mmSquare Excellent Thermal Ccm Mould Tube 8mm Copper Tube 135 X 135mm

FAQ

Q1. What is the advantage about your company?

A1. Our company has professional team and professional production line.

Q2. Why should I choose your products?

A2. Our products are high quality and low price.

Q3. When is the fastest delivery time?
A3. Depends on product type and quantity.


Product Tags:

135mm ccm mould tube



thermal ccm mould tube



Square Mould 8mm copper tube


Quality Square Excellent Thermal Ccm Mould Tube 8mm Copper Tube 135 X 135mm for sale

Square Excellent Thermal Ccm Mould Tube 8mm Copper Tube 135 X 135mm Images
